2.4 Technical Specifications

Screen

7 inch Capacitive Touch Screen. Five Points Multi-touch

Resolution: 800 x 480. Aspect Ratio: 16 : 9

CPU

Chipset: ALLWINNER; Processor: Cortex A8; Frequency: 1.2GHz

RAM

DDR3 512 MB

Storage

4GB-16GB optional

External inserted TF card be extendable from 1GB to 16 GB

System

Android 2.3

Network

Wifi: Built-in Wifi Module. IEEE 802.11b/g/n. 11Mbps to 54Mbps

3G: External 3G by USB Dongle.

Applications

APK format applications

Video

RM, RMVB, AVI, MOV, WMV, MP4, ASF, 3GP, TS, MKV, MPEG, etc.

All videos support HD 2160P.

Music

MP3, WMA, WAV, APE, FLAC, AAC, OGG, etc.

Pictures

JPG, BMP, PNG, TIFF, etc.

Ebooks

TXT, PDF, CHM, HTML, PDB, UMD, FB2, LRC, EPUB.

Office Files

Supported files: Word, Excel, PDF, etc.

PC Connection

MINI USB 2.0 x 1

Battery

Built-in Lithium Battery: 3200 mAh.

3. Quick Guides

3.1 About Touch Panel

The touch screen is capacitive touch screen; you can use five fingers to touch the screen at the

same time.

3.2 Switch On/Off

Switch On and Unlock: When the device is in the OFF mode, press and hold “Power” key for 3

seconds to enter the Android startup progress bar, it need about 20 seconds enter to the system

desktop, when the LCD is under locked mode, please press and pull the icon to the green

point, then the LCD will unlocked automatically, see the figures below.
